Workflow library (DNN)

Approval chains repeat — manager sign-off, two-stage finance approval, auto-invoice on completion. The Library stores workflows as reusable, versioned templates you attach to forms instead of redrawing them.

The workflow Library on DNN: browsing saved flows and samples from the BPMN editor, with suggested variable mappings (Amount, Country, …) when binding one to the current form

Using it

  • Library (BPMN editor toolbar) — the saved flows on this site; Samples ships ready-made patterns to start from.
  • Save to library — publish the current diagram as a template others can attach.
  • Attach to a form — pick a library flow and bind it: the editor proposes variable mappings from the flow's inputs to the current form's fields (Use suggested: Amount / Country / Currency…) so a generic "approve if amount is high" template snaps onto any form that has an amount.

Versioning & governance

Library workflows are versioned — forms bind to a pinned version by default, so editing a template later never silently changes a production form's behavior; rebind to upgrade. One template can serve many forms (each with its own mappings), which is how a site keeps a single canonical "finance approval" instead of five drifting copies.

A form can carry both: its own inline diagram OR a library binding — the BPMN editor shows which is active, and Apply always validates before anything goes live.
